External Screw Pressure Plate Back and Side Wired; Accepts #14 to #10 Wag Copper or Copper-Clad Conductors; Heavy Gauge One-Piece Copper Alloy Contact Arm Virtually Eliminates Contact Bounce; Cam Controls Fast Make and Positive Break to Minimize Arcing; Heavy Duty Bumper Pads for Quiet Operation; Locking Support Provides Resistance to Face and Back Body Separation; Oversized Silver Alloy Contacts for Long Life and Better Heat Dissipation; Grounding Terminal is Standard; Shallow Design for Ease of Installation; Strap Nickel Plated Steel with Integral Ground; Auto Ground Clip Assures Positive Ground
Applicable Standard NEMA WD-1/WD-6
Toggle Switch; Type Toggle; Voltage Rating 120 VAC; Current Rating 20 Ampere; Operation Type 3-Way; Wiring Back, Side; Wall Plate Included No; Material Glass Reinforced Nylon Body, Nylon Cover, Thermoplastic Polycarbonate Toggle; Color Clear; Size 1.32 Inch W x 1.073 Inch D x 3.281 Inch H; Application Specification Grade; Approval UL 20, CSA C22.2; Applicable Standard NEMA WD-1/WD-6
Specs
- Condition: Brand New
- Brand: Pass & Seymour
- Item ID: PS20AC3CPL
- Warranty: 1 Year Limited
- Manufacturer: Pass & Seymour
- Product Type: Toggle Switch
Document Downloads
Additional Part Number Information:
- Equivalent Part Number: PS20AC3CPL
- Supplies Depot Part Number: 29443
