Non-Drift Silicon Light Sensor with IR Filter; DC Relay with Zero-Crossing Circuitry for Extended Life; Conformal Coated PCB; 15-Year Design Life; Fail ON Mode; Ideal for Single or Multifixture HID and LED Installations; Zero-Cross Technology Helps Device withstand Severe Inrush Current and Extend Relay Life; 8 Year Warranty Limited
120 to 277 VAC 50/60 Hz, 1000 W Tungsten, 1800 VA Ballast, 18 AWG 9 inch Wire Lead Terminal, Polycarbonate, Button Style, Electronic Photocontrol
Includes 255 J MOV Surge Protection Element; Time Delay 2 to 5 Sec
Photo Control; Type Button; Voltage Rating 120 to 277 VAC at 50/60 Hz; Tungsten Load Rating 1000 W; Ballast Load Rating 1800 VA; Turn ON Light Level 1.5 FC; Turn OFF Light Level 2.25 FC; Terminal Type 18 AWG 9/6 Inch Wire Lead; Temperature Rating -40 to 158 Deg F; Mounting 1/2 Inch-14 NPSM Stem; Size 1-5/16 Inch W x 1-1/4 Inch D x 2-1/4 Inch H; Application Electrical Boxes, In-Wall Boxes, Outdoor Lighting Fixtures; Approval UL (Canada and US), CSA (Canada and US); Includes 255 J MOV Surge Protection Element; Time Delay 2 to 5 Sec
Specs
- Condition: Brand New
- Brand: Intermatic
- Item ID: EK4036S
- Warranty: 1 Year Limited
- Manufacturer: Intermatic
- Product Type: Photo Control
Document Downloads
Additional Part Number Information:
- Equivalent Part Number: EK4036S
- Supplies Depot Part Number: 1184593
