Description
Broad Wire Range 750 KCMIL to 14 Flexibility in the Field Dual Rated for Copper or Aluminum Conductor; Black Cover is UV Rated; Removable Plug Entry Port Closure; Prefilled with De-Ox Prevents Oxides from Forming; UL Listed and CSA Certified for 600 Volt, 90 Degree C Ensures Reliability; Cold Temperature Rated to 45 Deg C Application Variability; High Dielectric Strength Plastisol Chemical Resistant; Removable Plug Entry Port Closure
600 V, 14 to 4 AWG, Copper/Aluminum Conductor, Plastisol Insulated, 1-Side Entry, 2-Port, Mechanical Multi-Tap Connector
Size 1.24 Inch L x 1.22 Inch W x 1.42 Inch H; Screw Size 1/8 Inch Hex; Current Rating 95 Ampere; Temperature Rating 90 Deg C, -45 Deg C (Cold)
Multi-Tap Connector; Voltage Rating 600 V; Number of Ports 2; Cable Entry 1 Side Entry; Conductor Material Copper/Aluminum; Minimum Conductor Size 14 AWG; Maximum Conductor Size 4 AWG; Body Material High Dielectric Strength Plastisol Insulated; Approval UL 453G, UL 486A/B, CSA; ROHS Compliant; Size 1.24 Inch L x 1.22 Inch W x 1.42 Inch H; Screw Size 1/8 Inch Hex; Current Rating 95 Ampere; Temperature Rating 90 Deg C, -45 Deg C (Cold)
Specs
- Condition: Brand New
- Brand: ILSCO
- Item ID: PBTS24
- Manufacturer: ILSCO
- Product Type: Multi-Tap Connector
Document Downloads
Additional Part Number Information:
- Equivalent Part Number: PBTS24
- Supplies Depot Part Number: 83686
